ZOTAC GAMING GeForce RTX 5070 Twin Edge
ZT-B50700E-10P
The ZOTAC GAMING GeForce RTX 5070 Twin Edge is a compact graphics card powered by NVIDIA‘s cutting edge Blackwell Architecture, DLSS4 and 12GB of GDDR7 memory. Compact yet powerful, the Twin Edge is ready to take on both gaming and AI workloads with its impressive performance.
Feature Highlights:
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- NVIDIA SFF-Ready Enthusiast GeForce Card
- Compact dual-fan form factor
- IceStorm 2.0 Cooling
- BladeLink Fans
- FREEZE Fan Stop
- Metal Backplate
- Power Safety Light
- All-new FireStorm Utility
| Specification | GeForce RTX 5070 |
|---|---|
| GPU Architecture | Blackwell |
| CUDA Cores | 6144 |
| Base Clock | 2.16 GHz (2160 MHz) |
| Boost Clock | 2.51 GHz (2512 MHz) |
| Video Memory | 12GB GDDR7 |
| Memory Bus | 192-bit |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x16 |
| Display Outputs | 3 x DisplayPort 2.1b, 1 x HDMI 2.1b |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended Power Supply | 650W |
| Power Consumption | 250W |
| Power Input | 1 x 12v-2x6 power input |
| DirectX Support | DirectX 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling | IceStorm 2.0 |
| Slot Size | 2 |
| SLI | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809+) |
| Card Dimensions (LxWxH) | 241.5mm x 120.1mm x 40.6mm |
| Accessories | User Manual, 2 x 8-pin-to-16-pin cable |
